C01H2WS4 Outdoor Wireless Wifi AP HD IR IP Camera Audio I/O 720P 1.0MP 32GB TF ONVIF P2P


OS

Parameters

kernel

System

Linux

Processor

HI 3518

Video

Image sensor

1/4 1.0 MP OV CMOS image sensor

Video Codec

H.264 main profile and baseline

LEN

3.6mm,other lens optional

IR LED

4PCS IR LEDs

IR distance

20M-30M

Support mobile phone

All phone

P2P

PHONE,IE,P2P Client global Internet

Video Resolution

720P

First stream:1280*720

Second stream:640x352

Three stream:320x176

frame rate

PAL:25fps(50HZ),NTSC:30fps(60HZ)

Video compression

32Kbits/S~6.2Mbits/S

Min.Lux

0Lux

Store

SD card

Built in 32GB SD Card stroe(16GB,64GB,128GB option)

Client/Browser

Support

Record

Client

support

Browser

Support

SD CARD

Support

Playback

Client

support

Browser

Support

SD CARD

Support

SD Card

32GB
Support 720P real-time record and playback

Support SD card recorded file copy to your computer

Audio

Audio input

Support(Need extra microphone)

Audio output

Support(Need extra speaker)

Audio Codec

G.726/G.711

Internet

Internet face

10Base-T/100Base-TX,WIFI/802.11b/g/n wireless

Network Protocol

TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP

Access Protocol

ONVIF 2.3

Alarm

Motion detection

At most 4 respective regions

Alarm linkage

Alarm picture send E-mail, alarm images upload FTP server

Snap

Time snap

Regular support capturing images to the FTP server

safe

User management

Provide three levels of rights management (admin, user, guest), support to modify login user name and password

Other

Inter Power、consumption

DC12V 2A 、24W

Working temperature

-40℃ ~ +55℃

Working Humidity

10-95%


1 x 1.0MP Wifi IP Camera

1 x built-in 32 GB TF card

1 x Bracket

1 x Power Adapter

1 x CD within manual and software
